The main beam is made of HG high-strength steel with superior load capacity.
Side beams adopt H-beam structure. The robust design effectively prevents deformation.
The loading ramps are fabricated from high-strength steel. They bear heavy loads without distortion during transportation of heavy equipment.
Coated with polyurethane paint for long service life and effective rust protection.
Equipped with spare parts of world-renowned brands to guarantee reliable quality and cut costs.
| Parameter | Description |
|---|---|
| Load capacity | 80 tons |
| Overall dimensions (L×W×H) | 16,000mm × 3,000mm × 3,400mm |
| Axle | 3-axle |
| Suspension | Heavy-duty mechanical spring suspension |
| Tires | 12 units |
| Kingpin | 90# |
| Landing gear | JOST |
| Brake system | WABCO |
| Electrical system | 24V with LED lights |

The main beam is made of HG high-strength steel with superior load capacity.
Side beams adopt H-beam structure. The robust design effectively prevents deformation.
The loading ramps are fabricated from high-strength steel. They bear heavy loads without distortion during transportation of heavy equipment.
Coated with polyurethane paint for long service life and effective rust protection.
Equipped with spare parts of world-renowned brands to guarantee reliable quality and cut costs.
