Product Overview
The Multi-Functional Transporter is a versatile and heavy-duty transportation solution designed to handle a wide range of cargo types across various industries. Whether you need to transport construction machinery, agricultural equipment, containers, bulk goods, or oversized industrial components, this transporter delivers exceptional adaptability and performance.
Unlike traditional single-purpose trailers, the multi-functional transporter features a modular design that allows for quick configuration changes. With optional accessories such as removable side walls, container locks, coil wells, and hydraulic ramps, this single trailer can replace multiple specialized vehicles, significantly reducing fleet costs and improving operational efficiency.
Built with high-strength steel and a reinforced frame, the multi-functional transporter offers excellent load-bearing capacity while maintaining a lightweight structure for better fuel economy. The optimized chassis design ensures low center of gravity, providing superior stability during highway transit and off-road operations.
Key Applications
Construction: Excavators, bulldozers, loaders, rollers
Agriculture: Tractors, harvesters, crop storage bins
Logistics: 20ft/40ft containers, palletized goods, steel coils
Energy: Wind turbine components, transformers, generator sets
Mining: Heavy mining equipment, ore buckets
Core Advantages
Specifications
| Parameter | Description |
|---|
| Overall Dimensions (L×W×H) | 11,000mm – 16,000mm × 2,500mm – 3,000mm × 1,500mm – 1,650mm (customizable) |
| Load Capacity (Payload) | 50 – 100 tons |
| Axle | 2 – 5 axles (configurable); Brands: BPW, FUWA, SAF |
| Suspension | Mechanical suspension / Air suspension (optional) |
| Main Beam Material | Q345B / Q550D / T700 high-strength steel |
| Floor Plate | 3mm – 6mm checker plate (diamond pattern) |
| Tires | 8 – 20 units; Specifications: 11.00R20, 12.00R20, 12R22.5, 315/80R22.5 |
| Kingpin | 2" (50mm) or 3.5" (90mm); JOST brand |
| Landing Gear | 28-ton capacity, 2-speed; JOST brand |
| Brake System | Dual-line pneumatic brake system; WABCO valves |
| ABS | Optional; WABCO 4S/2M |
| Electrical System | 24V with 7-core socket; LED lights |
| Optional Accessories | Removable side walls, hydraulic ramps, container twist locks, coil well, tool boxes |
| Paint | Epoxy primer + polyurethane topcoat; color customizable |
| Packaging | Anti-rust wax coating before shipment |
